August 2003

118/122

Rev. 2.5

ERRATA SHEET

ST7LITE0, ST7SUPERLITE

LIMITATIONS AND CORRECTIONS

18 SILICON IDENTIFICATION

This section of the document refers to rev Y ST7FLITE0 and ST7FLITES2/S5 devices.

They are identifiable:

On the device package, by the last letter of the Trace code marked on the device package

On the box, by the last 3 digits of the Internal Sales Type printed on the box label.

Table 25. Device Identification

See also Figure 95

19 REFERENCE SPECIFICATION

Limitations in this document are with reference to the ST7LITE0, ST7SUPERLITE

Datasheet Revision 2.4 (August 2003).

20 SILICON LIMITATIONS

20.1 NEGATIVE INJECTION IMPACT ON ADC ACCURACY

Injecting a negative current on an analog input pins significantly reduces the accuracy of the

AD Converter. Whenever necessary, the negative injection should be prevented by the addi-

tion of a Schottky diode between the concerned I/Os and ground.

Injecting a negative current on digital input pins degrades ADC accuracy especially if per-

formed on a pin close to ADC channel in use.

Trace Code marked on device

Internal Sales Type on box label

Flash Devices:

“xxxxxxxxxY”

7FLITE09Y0M6$U5

7FLITE09Y0B6$U5

7FLITE05Y0M6$U5

7FLITE05Y0B6$U5

7FLITE02Y0M6$U5

7FLITE02Y0B6$U5

7FLITES5Y0M6$U5

7FLITES5Y0B6$U5

7FLITES2Y0M6$U5

7FLITES2Y0B6$U5
