Mechanical Specifications

Size

Length

0.51 in [12.95 mm]

Width/Dia.

0.156 in [3.96 mm]

.

.

Mating Cycles

500 Cycles

Mating Torque

1.75 to 2 in-lbs [0.20 to 0.23 Nm]

Material Specifications

Description

Material

Plating

Contact

Beryllium Copper

Gold

MIL-PRF-39012

Insulation

Teflon

Outer Conductor

Beryllium Copper

Gold

MIL-PRF-39012

Body

Brass

Gold

MIL-PRF-39012

Washer

Brass

Gold

MIL-PRF-39012

.

Environmental Specifications

Temperature

Operating Range

-65 to +165 deg C

Shock

Method 213, Condition B, 75G @6ms @1/2 sine

Vibration

Method 204, Condition D (20G)

Salt Spray

Method 101, Condition B, 5% salt solution

Plotted and Other Data

Notes:

PE45375 REV 1.0

Click the following link (or enter part number in “SEARCH” on website) to obtain additional part information including price,

inventory and certifications: SSMC Jack Bulkhead Mount Connector Solder Attachment Turret Terminal PE45375

RF Connectors Technical Data Sheet

PE45375

SSMC Jack Bulkhead Mount Connector

Solder Attachment Turret Terminal
