Data Sheet

ADL5320

SPECIFICATIONS

TA = 25°C, unless otherwise noted.

Table 1.

3.3 V

5 V

Parameter

Test Conditions/Comments

Min

Typ

Max

Min

Typ

Max

Unit

OVERALL FUNCTION

Frequency Range

400

2700

400

2700

MHz

FREQUENCY = 880 MHz

Gain1

15.6

16.3

16.9

17.5

vs. Frequency

±50 MHz

±0.2

±0.3

vs. Temperature

−40°C ≤ TA ≤ +85°C

±0.6

vs. Supply

3.2 V to 3.4 V, 4.75 V to 5.25 V

±0.2

±0.1

Output 1 dB Compression Point

21.5

25.4

dBm

Output Third-Order Intercept

∆f = 1 MHz, POUT = 10 dBm per tone

dBm

Noise Figure

3.2

4.1

FREQUENCY = 2140 MHz

Gain1

12.2

12.4

13.2

14.0

vs. Frequency

±50 MHz

±0.3

±0.33

vs. Temperature

−40°C ≤ TA ≤ +85°C

±0.7

±0.8

vs. Supply

3.2 V to 3.4 V, 4.75 V to 5.25 V

±0.15

±0.06

Output 1 dB Compression Point

22.6

25.7

dBm

Output Third-Order Intercept

∆f = 1 MHz, POUT = 10 dBm per tone

dBm

Noise Figure

3.7

4.4

FREQUENCY = 2600 MHz

Gain1

10.7

11.5

12.5

13.4

vs. Frequency

±100 MHz

±0.2

±0.6

vs. Temperature

−40°C ≤ TA ≤ +85°C

±0.6

±1.1

vs. Supply

3.2 V to 3.4 V, 4.75 V to 5.25 V

±0.2

±0.1

Output 1 dB Compression Point

25.7

27.4

dBm

Output Third-Order Intercept

∆f = 1 MHz, POUT = 10 dBm per tone

dBm

Noise Figure

4.1

5.1

POWER INTERFACE

Pin RFOUT

Supply Voltage

3.3

4.5

5.5

Supply Current

104

124

vs. Temperature

−40°C ≤ TA ≤ +85°C

±5.0

±6.0

Power Dissipation

VSUP = 3.3 V, VSUP = 5 V

145

520

1 Guaranteed maximum and minimum specified limits on this parameter are based on six sigma calculations.

Rev. B | Page 3 of 20
