78LXXM

LINEAR INTEGRATED CIRCUIT

UNISONIC TECHNOLOGIES CO., LTD

3 of 8

www.unisonic.com.tw

QW-R101-002.N



ABSOLU T E M AX I M U M RAT I N GS

(Operating temperature range applies unless otherwise specified.)

PARAMETER

SYMBOL

RATINGS

UNIT

30

V

Input Voltage

35

V

Output Current

200

mA

SOP-8

500

TO-92

625

TO-92L

800

TO-92NL

800

SOT-89

350

Power Dissipation

SOT-223

750

mW

Ambient Operating Temperature

-40 ~ +85

°C

Storage Temperature

-55 ~ +150

°C

Note Absolute maximum ratings are those values beyond which the device could be permanently damaged.

Absolute maximum ratings are stress ratings only and functional device operation is not implied.



ELECT RI CAL CH ARACT ERI ST I CS

PARAMETER

SYMBOL

TEST CONDITIONS

MIN

TYP

MAX

UNIT

4.80

5.0

5.20

V

4.75

5.25

V

Output Voltage

4.75

5.25

V

(Note 2)

15

60

mV

Load Regulation

V

OUT

8

30

mV

8

150

mV

Line Regulation

V

OUT

6

100

mV

Quiescent Current

2.0

5.5

mA

I

Q

1.5

mA

Quiescent Current Change

0.1

mA

Output Noise Voltage

10Hz≦f≦100kHz

40

μV

V

-0.65

mV/°C

Ripple Rejection

RR

60

dB

Dropout Voltage

1.7

V

PARAMETER

SYMBOL

TEST CONDITIONS

MIN

TYP

MAX

UNIT

5.76

6.0

6.24

V

5.7

6.3

V

Output Voltage

5.7

6.3

V

(Note 2)

16

80

mV

Load Regulation

 V

OUT

9

40

mV

10

175

mV

Line Regulation

 V

OUT

8

125

mV

Quiescent Current

2.0

5.5

mA

1.5

mA

Quiescent Current Change

I

Q

0.1

mA

Output Noise Voltage

10Hz≦f≦100kHz

49

μV

V

-0.75

mV/

C

Ripple Rejection

RR

56

dB

Dropout Voltage

1.7

V
