PDM577x-R11 Datasheet(PDF) 3 Page - P-tec Corporation

Part # PDM577x-R11
Description  Gray or Black Face, White Segment
PDF  8 Pages
Scroll/Zoom Zoom In 100%  Zoom Out
Manufacturer  P-TEC [P-tec Corporation]
Direct Link  http://www.p-tec.net
Logo P-TEC - P-tec Corporation

PDM577x-R11 Datasheet(HTML) 3 Page - P-tec Corporation

  PDM577x-R11 Datasheet HTML 1Page - P-tec Corporation PDM577x-R11 Datasheet HTML 2Page - P-tec Corporation PDM577x-R11 Datasheet HTML 3Page - P-tec Corporation PDM577x-R11 Datasheet HTML 4Page - P-tec Corporation PDM577x-R11 Datasheet HTML 5Page - P-tec Corporation PDM577x-R11 Datasheet HTML 6Page - P-tec Corporation PDM577x-R11 Datasheet HTML 7Page - P-tec Corporation PDM577x-R11 Datasheet HTML 8Page - P-tec Corporation
Zoom Inzoom in Zoom Outzoom out
 3 / 8 page
background image


www.p-tec.net
102013 Rev0 JAS
Page 3 of 8
Electrical and Optical Characteristics at Ta=25°C
Parameter
Symbol
Chip
Min.
Typ.
Max.
Unit
Condition
Forward Voltage Per
Segment
VF
G05
--
3.2
3.8
V
IF=20mA
G17/Y04/A11
/R02/R11/R21
--
2
2.8
Luminous Intensity Per
Segment
Iv
G05
--
230
--
mcd
IF=10mA
G17
--
16
--
Y04
--
50
--
A11
--
60
--
R02
--
40
--
R11
--
40
R21
--
18
--
Peak Emission
Wavelength /
Dominant Wavelength
λP/λd
G05
--
*/525
--
nm
IF=20mA
G17
--
572/570
--
Y04
--
592/590
--
A11
--
612/605
--
R02
--
632/625
--
R11
--
644/630
--
R21
--
660/645
--
Reverse Current
IR
--
--
100
μA
VR=5V
Luminous Intensity
Matching Ratio
Iv-m
--
--
2:1
--
IF=10mA
