SD52-470-R Datasheet(PDF) 1 Page - Eaton All Rights Reserved. |
|
|
|||||||||||||||||||||||||||||
SD52-470-R Datasheet(HTML) 1 Page - Eaton All Rights Reserved. |
|
|
1 / 4 page  Technical Data 4311 Effective November 2015 Supersedes March 2007 Product description • Octagonal shape shielded drum core • Inductance range from 1.2 uH to 150 uH • Current range from 0.28 A to 3.14 A • 5.6 mm x 5.2 mm footprint surface mount package in a 2.0 mm height • Ferrite core material • Halogen free, lead free, RoHS compliant Applications • Desktop computers • Notebook and laptop regulators • Graphics cards • Digital cameras, media devices Environmental Data • Storage temperature range: -40 °C to +125 °C • Operating temperature range: -40 °C to +125 °C (ambient plus self-temperature rise). • Solder reflow temperature: J-STD-020D compliant Pb HALOGEN HF FREE SD52 High power density, low profile shielded power inductors |
