DFN1006 PACKAGE OUTLINE & DIMENSIONS
ULC3311CDN
Symbol
Dimensions In
Millimeters
Dimensions In
Inches
Min
Max
Min
Max
A
0.320
0.420
0.013
0.017
D
0.550
0.650
0.022
0.026
E
0.950
1.050
0.037
0.041
D1
0.450
0.550
0.018
0.022
E1
0.550
0.650
0.022
0.026
L
0.280
0.380
0.011
0.015
L1
0.000
0.100
0.000
0.004
Shanghai Leiditech Electronic Co.,Ltd
Email: sale1@leiditech.com
Tel : +86- 021 50828806
Fax : +86- 021 50477059
Rev 2.0 :
www.leiditech.com
12.01.2019
4/4
