MODEL: FUD

FUD SPECIFICATIONS

ES-1446 Rev.7 Page 3/3

http://www.m-system.co.jp/

EXTERNAL DIMENSIONS unit: mm (inch)

26 (1.02)

(.59)

2–4.5 (.18)

HOLE

15 (.59) deep

8–M3.5

SCREW

7.8 (.31)

107 (4.21)

DIN RAIL

35mm wide

[3.3 (.13)]

CLAMP

(top & bottom)

137 (5.39)

•When mounting, no extra space is needed between units.

26 (1.02)

TERMINAL ASSIGNMENTS unit: mm (inch)

INPUT RESISTOR

(model: REM)

Input shunt resistor attached

for current input.

SCHEMATIC CIRCUITRY & CONNECTION DIAGRAM

–

Base Socket

*Input shunt resistor attached for current input.

INPUT

Low Drift

Amplifier

Reverser

Output

Driver

OUTPUT

U(+)

V(–)

POWER

Specifications are subject to change without notice.
