3 / 3 page

MODEL: KADS

KADS SPECIFICATIONS

ES-3638 Rev.5 Page 3/3

http://www.m-system.co.jp/

EXTERNAL DIMENSIONS unit: mm (inch)

50 (1.97)

103 (4.06)

123 (4.84)

[3.3 (.13)]

40 (1.57)

50 (1.97)

7.8 (.31)

CLAMP

(top & bottom)

DIN RAIL

35mm wide

2–4.5 (.18) dia.

MTG HOLE

15 (.59) deep

8–M3.5

SCREW

• When mounting, no extra space is needed between units.

TERMINAL ASSIGNMENTS unit: mm (inch)

INPUT RESISTOR

(model: REM)

Input shunt resistor attached

for current input.

SCHEMATIC CIRCUITRY & CONNECTION DIAGRAM

–

Isolation

Base Socket

*Input shunt resistor attached for current inputs.

Adder

Output

Driver

OUTPUT

U(+)

V(–)

POWER

–

INPUT 1

–

INPUT 2

Low Drift

Amplifier

Low Drift

Amplifier

Specifications are subject to change without notice.
