Product data sheet

Characteristics

RXM2AB2P7PVM

Harmony, Miniature plug-in relay pre-assembled,

10 A, 2 CO, with LED, with lockable test button,

mixed terminals socket, 230 V AC

Product availability : Non-Stock - Not normally stocked in distribution facility

Price* : 25.18 USD

Main

Range of product

Harmony Electromechanical Relays

Series name

Miniature

Product or component type

Pre-assembled plug-in relay with socket

Device short name

RXM

Contacts type and composition

2 C/O

[Uc] control circuit voltage

230 V AC 50/60 Hz

[Ithe] conventional enclosed thermal

current

10 A -40…131 °F (-40…55 °C)

Status LED

With

Control type

Lockable test button

Utilisation coefficient

20 %

Complementary

[Ui] rated insulation voltage

250 V IEC

[Uimp] rated impulse withstand voltage

4 kV 1.2/50 µs

Contacts material

AgNi

[Ie] rated operational current

6 A 28 V DC) NC IEC

6 A 250 V AC) NC IEC

10 A 28 V DC) NO UL

10 A 250 V AC) NO UL

Minimum switching current

10 mA

Maximum switching voltage

250 V

Minimum switching voltage

17 V

Resistive rated load

10 A 250 V AC

10 A 28 V DC

*  Price is “List Price” and may be subject to a trade discount – check with your local distributor or retailer for actual price.
