PLL601-01
Low Phase Noise PLL Clock Multiplier
47745 Fremont Blvd., Fremont, California 94538 Tel (510) 492-0990 Fax (510) 492-0991 www.phaselink.com Rev 09/03/04 Page 4
4. Crystal Specifications
PARAMETERS
SYMBOL
CONDITIONS
MIN.
TYP.
MAX.
UNITS
Crystal Resonator Frequency
FXIN
Parallel Fundamental Mode
10
27
MHz
Crystal Loading Capacitance
Rating
CL (xtal)
15
pF
5. Jitter Specifications
PARAMETERS
CONDITIONS
MIN.
TYP.
MAX.
UNITS
Max. Absolute Jitter, peak-to-peak
Short term
±100
ps
Max. Jitter, cycle to cycle
60
ps
Phase Noise, relative to carrier, 125Mhz(x5)
100 Hz offset
105
dBc/Hz
Phase Noise, relative to carrier, 125Mhz(x5)
1kHz offset
125
dBc/Hz
Phase Noise, relative to carrier, 125Mhz(x5)
10kHz offset
130
dBc/Hz
Phase Noise, relative to carrier, 125Mhz(x5)
100kHz offset
125
dBc/Hz
