PLL601-12

Dual Output PLL Clock with Selectable Odd Multiplier

47745 Fremont Blvd., Fremont, California 94538 Tel (510) 492-0990 Fax (510) 492-0991 www.phaselink.com Rev 09/03/04 Page 4

5. Jitter Specifications

PARAMETERS

CONDITIONS

MIN.

TYP.

MAX.

UNITS

Max. Absolute Jitter, peak-to-peak

Short term

60

100

ps

Max. Jitter, cycle to cycle

60

ps

Phase Noise, relative to carrier, 125Mhz(x5)

100 Hz offset

105

dBc/Hz

Phase Noise, relative to carrier, 125Mhz(x5)

1kHz offset

125

dBc/Hz

Phase Noise, relative to carrier, 125Mhz(x5)

10kHz offset

130

dBc/Hz

Phase Noise, relative to carrier, 125Mhz(x5)

100kHz offset

125

dBc/Hz
