background image
Electrical Characteristics(TA=25°C unless otherwise specified)
Rev 2.0 :
www.leiditech.com
2/4
ULC3311CDN
01.08.2021
Q
Parameter
Symbol
Min
Typ
Max
Unit
Test Condition
Reverse Working Voltage
VRWM
3.3
V
Breakdown Voltage
VBR
4.2
V
IT = 1mA
Reverse Leakage Current
IR
0.1
µA
VRWM = 3.3V
Clamping Voltage
VC
10
V
IPP = 1A (8 x 20 s pulse)
Clamping Voltage
VC
14
V
IPP = 4A (8 x 20 s pulse)
Junction Capacitance
CJ
0.45
pF
V = 0V, f = 1MHz
μ
μ
R
0.8
