MBR0540
DIODE
UNISONICTECHNOLOGIESCO.,LTD
2 of 3
www.unisonic.com.tw
QW-R601-013,A
ABSOLUTE MAXIMUM RATINGS (Single Diode @TA=25℃)
PARAMETER
SYMBOL
RATINGS
UNIT
Maximum Repetitive Peak Reverse Voltage
VRRM
40
V
Maximum DC Blocking Voltage
VR
40
V
Working Peak Reverse Voltage
VRWM
40
V
Maximum RMS Reverse Voltage
VR(RMS)
28
V
Maximum Voltage Rate of Change (Rated VR)
dv/dt
1000
V/µs
Average Rectified Forward Current
IOUT
500
mA
Non-Repetitive Peak Forward Surge Current
IFSM
5.5
A
Power Dissipation
PD
410
mW
Storage Temperature
TSTG
-65 ~ +150
℃
Note: Absolute maximum ratings are those values beyond which the device could be permanently damaged.
Absolute maximum ratings are stress ratings only and functional device operation is not implied.
THERMAL DATA
PARAMETER
SYMBOL
RATINGS
UNIT
Thermal Resistance Junction to Ambient
θJA
244
℃
/W
ELECTRICAL CHARACTERISTICS (TA=25℃, unless otherwise specified)
PARAMETER
SYMBOL
TEST CONDITIONS
MIN
TYP
MAX
UNIT
Reverse Breakdown Voltage
BVR
IR=20µA
40
V
VF1
IF=0.5A
0.51
Forward Voltage Drop
VF2
IF=1A
0.62
V
IR1
VR=20V
10
Reverse Leakage Current
IR2
VR=40V
20
µA
Total Capacitance
CT
VR=1V, f=1MHz
170
pF
Typical Reverse Recovery Time
tRR
IF=IR=10mA, RL=100Ω,
recover to 0.1 x IR
4
ns
