7 / 32 page

ADL5375

Rev. 0 | Page 7 of 32

ABSOLUTE MAXIMUM RATINGS

Table 2.

Parameter

Rating

Supply Voltage, VPOS

5.5 V

IBBP, IBBN, QBBP, QBBN

0 V to 2 V

LOIP and LOIN

13 dBm

Internal Power Dissipation

ADL5375-05

1500 mW

ADL5375-15

1200 mW

θJA (Exposed Paddle Soldered Down)1

54°C/W

Maximum Junction Temperature

150°C

Operating Temperature Range

−40°C to +85°C

Storage Temperature Range

−65°C to +150°C

1 Per JDEC standard JESD 51-2. For information on optimizing thermal

impedance, see the Thermal Grounding and Evaluation Board Layout section.

Stresses above those listed under Absolute Maximum Ratings

may cause permanent damage to the device. This is a stress

rating only; functional operation of the device at these or any

other conditions above those indicated in the operational

section of this specification is not implied. Exposure to absolute

maximum rating conditions for extended periods may affect

device reliability.

ESD CAUTION
