Part #	JN2AS04MK2X-R

Description	Small circular connector, With construction having earth function, 4 pos., Panel mount receptacle

PDF	3 Pages

Scroll/Zoom	100%

Manufacturer	JAE [Japan Aviation Electronics Industry, Ltd.]

Direct Link	http://www.jae.com

Logo

2 / 3 page

Contact Size X No. of Contacts

#20*4

Applicable Wire (Cross-

sectional Area of Conductor)

Applicable Wire Insulation

Diameter

Polarizing Key Position

X position

Material of Contact

copper alloy

Finish of Contact in Connecting

Area

Silver plating

Outer Shell Color

Black

Total Current Rating (A)

Contact Resistance (milliohm)

Dielectric Withstanding

Voltage (1 minute)

2,000VAC

Insulation Resistance

1,000MΩMIN

Mating Cycles

500 times

Operating Temperature Range

-20 Deg. C to +100 Deg. C

Applicable Contacts

Applicable Housing

Applicable Accessory

Applicable Product Part

Numbers

Applicable Wire Diameter

RoHS compliant

10 substances (2011/65/EU, (EU)2015/863)

REACH compliant

Combination

JN1DS04FK1X

JN1DS04FK2X

JN1FS04FK1X

JN1FS04FK2X

JN2DS04FK1X-R

JN2DS04FK2X-R

JN2DS04FKKX-R
