4 / 40 page

A22E

Lighted Models

* Models with Korean S-mark certification

Switch with Integrated Control Box

Note: The A22Z-B101Y Control Box is used.

* Models with Korean S-mark certification

Operation

Push-lock turn-reset system

Color of cap

Appearance

Contacts

(Number of

switch blocks)

LED Lamp voltage

Set Model

40-dia. head

Push-lock

Turn-reset

Lighting unit

(Direct lighting)

A22E

1NC (1)

6 VAC/VDC

A22EL-M-6A-01

Red

12 VAC/VDC

A22EL-M-12A-01

24 VAC/VDC

A22EL-M-24A-01

1NC, 1NO (2)

6 VAC/VDC

A22EL-M-6A-11

12 VAC/VDC

A22EL-M-12A-11

24 VAC/VDC

A22EL-M-24A-11

2NC (2)

6 VAC/VDC

A22EL-M-6A-02

12 VAC/VDC

A22EL-M-12A-02

24 VAC/VDC

A22EL-M-24A-02

40-dia. head

Push-lock

Turn-reset

Lighting unit

(Voltage-

reduction lighting)

A22E

1NC (1)

100 VAC

A22EL-M-T1-01

200 VAC

A22EL-M-T2-01

1NC, 1NO (2)

100 VAC

A22EL-M-T1-11

200 VAC

A22EL-M-T2-11

2NC (2)

100 VAC

A22EL-M-T1-02

200 VAC

A22EL-M-T2-02

Appearance

Contact configuration (Number of switch blocks)

Model

1NC (1)

A22E-M-01B

1NC, 1NO (2)

A22E-M-11B

2NC (2)

A22E-M-02B
