1 / 1 page Isometric View 1:2 R This Drawing is the property of 35 Royal Road Flemington, NJ 08822-6000 (908) 806-9400 Fax (908) 806-9490 and is a confidential disclosurelent without consideration other than the borrower’s agreement that it shall not be reproduced, copied, lent or disposed of directly or indirectly nor used for any purpose other than that for which it is specifically furnished. unless otherwise specified: all dimensions are in millimeters third angle projection M E T R I C tolerance XX XX.X XX.XX ALL ±1 mm ±0.5 mm ±0.2 mm − mm = = = = titel drawn by: checked by: released by: drawing no.: rev.: scale: sheet: of: Laszlo Gyorgypal 11/2/2007 11/2/2007 Philipp Ernstberger 11/2/2007 22 mm Thermoplastic Enclosures White/Black Operator Capacity 2 3-001-R-11 1PB-3-001-R-11 - - 1 1 Laszlo Gyorgypal revision for dwg # 1PB-3-001-R-11 rev - ch.no. - description original design date revised by 11/2/2007 Philipp E. 103.57 mm [4.1 in] 50.60 mm [2.0 in] R11.20 mm [.4 in] 2x PG 13.5 or M20 Plastic enclosure suited for non-illuminated push buttons with maximum 2 contact elements. |
