OST08WG01GD-R5RUT831A Datasheet(PDF) 2 Page - OptoSupply International

Part # OST08WG01GD-R5RUT831A
Description  T08 Round AUTO LED
PDF  2 Pages
Scroll/Zoom Zoom In 100%  Zoom Out
Manufacturer  OPTOSUPPLY [OptoSupply International]
Direct Link  http://www.optosupply.com
Logo OPTOSUPPLY - OptoSupply International

OST08WG01GD-R5RUT831A Datasheet(HTML) 2 Page - OptoSupply International

  OST08WG01GD-R5RUT831A Datasheet HTML 1Page - OptoSupply International OST08WG01GD-R5RUT831A Datasheet HTML 2Page - OptoSupply International
Zoom Inzoom in Zoom Outzoom out
 2 / 2 page
background image
2
Device Selection Guide
1
Module No.
Color
Wavelength
(Typ.)
Intensity / Per
LED
(Typ.)
Overall
luminous flux
R5RUT831A
Red
625 nm
3200mcd
1.0lm
G5DUT831A
Green
525 nm
34500mcd
3.5lm
B5YUT831A
Blue
470 nm
7500mcd
0.6lm
Y5RUT831A
Yellow
590 nm
3200mcd
1.0lm
W5YKT831A
White
X=0.27,Y=0.28
15000mcd
3.0lm
Absolute Maximum Ratings(Ta=25℃)
1
Items
Symbol
Values
Units
Operating supply range(DC)
Vidc
16
V
Input Current (DC)
Ii
30
mA
Power Dissipation
Pa
0.48
W
Operating Temperature
Tope
-10 ~ +40
DegC
Storage Temperature
Tstg
-20 ~ +80
DegC
Typical Performance (Ta=25℃)
1
Items
Symbol
Min.
Typ.
Max.
Units
LED Module Power
Pm
-
0.24
0.48
w
Input Voltage(DC)
Vi
-
12
16
V
Product input Current
If
-
20
30
mA
Beam Pattern
BP
-
30
-
Deg
Total diameter of PCB
Lmod.
-
25.3
-
mm
Net Weight
Wei.
---
1.2
---
g
Model No.
OST08WG01GD-
XXXXT831A
REV.
C1



Html Pages

1 2
