B40-P & B40-H

Liquid Level Switch

ASME B31.1 Compliant

D E S C R I P T I O N

Magnetrol B40-P & B40-H liquid level switches are

utilized

in

high

pressure,

high

temperature

service

conditions. They are designed, constructed and certified

to the ASME B31.1 Power Piping code.

F E A T U R E S

• Choices of chamber materials are carbon steel,

stainless steel and chrome-moly

• 300 series stainless steel float

• Choice of switch mechanism:

Dry contact

Hermetically sealed

• Minimum specific gravity 0.65

• Choice of switch mechanism enclosure:

TYPE 4X polymer coated steel

TYPE 4X/7/9 Class I, Div. 1, Groups C & D,

polymer coated aluminum or cast iron

TYPE 4X/7/9 Class I, Div. 1, Group B,

polymer coated aluminum or cast iron

• Choice of tank connection:

1" butt welds

1" or 1

1⁄2" socket welds

O P T I O N S

• ATEX housing

• Flanged connections

• Temperature extensions

• Low specific gravity calibration

• Additional QC testing

A P P L I C A T I O N S

• Accumulators

• Receivers

• Flash tanks

• Knock-out drums

• Storage tanks

• Separators

• Drip Legs
