US201XXG-AF5-R Datasheet(PDF) 2 Page - Unisonic Technologies

Part # US201XXG-AF5-R
Description  HIGH-SIDE POWER SWITCHES WITH FLAG
PDF  7 Pages
Scroll/Zoom Zoom In 100%  Zoom Out
Manufacturer  UTC [Unisonic Technologies]
Direct Link  http://www.utc-ic.com
Logo UTC - Unisonic Technologies

US201XXG-AF5-R Datasheet(HTML) 2 Page - Unisonic Technologies

  US201XXG-AF5-R Datasheet HTML 1Page - Unisonic Technologies US201XXG-AF5-R Datasheet HTML 2Page - Unisonic Technologies US201XXG-AF5-R Datasheet HTML 3Page - Unisonic Technologies US201XXG-AF5-R Datasheet HTML 4Page - Unisonic Technologies US201XXG-AF5-R Datasheet HTML 5Page - Unisonic Technologies US201XXG-AF5-R Datasheet HTML 6Page - Unisonic Technologies US201XXG-AF5-R Datasheet HTML 7Page - Unisonic Technologies
Zoom Inzoom in Zoom Outzoom out
 2 / 7 page
background image
US201/A/B/C
CMOS IC
UNISONICTECHNOLOGIESCO.,LTD
2 of 7
www.unisonic.com.tw
QW-R502-302.H
MARKING
3
2
1
5
4
US
Current Code:
1: 0.6A, A: 1.1A,
B: 1.3A, C: 1.5A
Logic Level Enable Pin
G: Halogen Free
L : Lead Free
PIN CONFIGURATION
PIN DESCRIPTION
PIN NO
PIN NAME
DESCRIPTION
1
CTL
Enable Input pin, H: High active, L: Low active
2
GND
Ground
3
FLG
Open-drain fault flag output
4
VIN
Power input voltage
5
VOUT
Output voltage
BLOCK DIAGRAM
