TECHNICAL DATA SHEET

N Female Press In Connector Solder Attachment Tab Terminal, .500 inch Diameter

Configuration

Connector

N Female

Connector Interface Type

Tab

Cable Attachment Method (Shield/Contact)

Solder

Body Style

Straight

Mount Method

Press In

Electrical Specifications

Impedance, Ohms

50

Mechanical Specifications

Size

Length, in [mm]

0.997 [25.32]

Width/Dia., in [mm]

0.625 [15.88]

.

Weight, lbs [g]

0.055 [24.95]

Connector

Type

N Female

Contact Material and Plating

Silver

Body Material and Plating

Brass, Nickel

RoHS Compliant

Yes

Plotted and Other Data

Notes:

Values at 25 °C, sea level

N Female Press In Connector Solder Attachment Tab Terminal, .500 inch Diameter from Pasternack Enterprises has same day

shipment for domestic and International orders. Our RF, microwave and fiber optic products maintain a 99% availability and

are part of the broadest selection in the industry.

Click the following link (or enter part number in “SEARCH” on website) to obtain additional part information including price,

inventory and certifications: N Female Press In Connector Solder Attachment Tab Terminal, .500 inch Diameter PE44075

URL: http://www.pasternack.com/n-female-standard-tab-terminal-connector-pe44075-p.aspx

PE44075

PE44075 REV

N Female Press In Connector Solder Attachment

Tab Terminal, .500 inch Diameter
