TECHNICAL DATA SHEET

FME Jack Connector Crimp/Solder Attachment For RG58

FME Jack Connector Crimp/Solder Attachment For RG58

Configuration

Connector

FME Jack

Connector Interface Type

RG58

Cable Attachment Method (Shield/Contact)

Crimp/Solder

Body Style

Straight

Electrical Specifications

Impedance, Ohms

50

Mechanical Specifications

Size

Length, in [mm]

1.268 [32.21]

Width/Dia., in [mm]

0.315 [8]

.

Weight, lbs [g]

0.013 [5.9]

Connector

Type

FME Jack

Contact Material and Plating

Brass, Gold

Body Material and Plating

Brass, Nickel

Dielectric Type

PTFE

RoHS Compliant

Yes

Plotted and Other Data

Notes:

Values at 25 °C, sea level

FME Jack Connector Crimp/Solder Attachment For RG58 from Pasternack Enterprises has same day shipment for domestic

and International orders. Our RF, microwave and fiber optic products maintain a 99% availability and are part of the broadest

selection in the industry.

Click the following link (or enter part number in “SEARCH” on website) to obtain additional part information including price,

inventory and certifications: FME Jack Connector Crimp/Solder Attachment For RG58 PE44146
