PAM2309
1A Step-Down DC-DC Converter
Load Transient
Io=0-500mA, Vo=3.3V, Vin=5V
Load Transient
Io=0-1A, Vo=1.2V, Vin=3.6V
9
,
Power Analog Microelectronics Inc
www.poweranalog.com
Typical Performance Characteristics
°C
T =25
,C =10 F, C =10 F, L=4.7 H, unless otherwise noted.
AIN
O
μμ
μ
Start-up from Shutdown
Vo=1.8V, Vin=3.6V
Voltage
Output
Enable
Inductor
Current
Voltage
Output
Output
Current
Voltage
Output
Output
Current
08/2009 Rev 1.1
