TECHNICAL DATA SHEET

Configuration

Connector

N Female

Connector Specification

MIL-STD-348

Heat Sink

Black Anodized Aluminum Heatsink

Connection Method

Standard

Body Style

Straight

Electrical Specifications

Frequency Range, GHz

DC to 18

Impedance, Ohms

50

Maximum VSWR

1.6:1

Maximum Input Power, Watts

25

Peak Power, Watts

500

Frequency 1

Frequency, GHz

DC to 6

VSWR

1.3:1

Frequency 2

Frequency, GHz

6 to 12.4

VSWR

1.45:1

Frequency 3

Frequency, GHz

12.4 to 18

VSWR

1.6:1

Mechanical Specifications

Temperature

Operating Range, deg C

-65 to +125

Width/Dia., in [mm]

2.3 [58.42]

.

Color

Black

Connector

Type

N Female

Inner Conductor Material and Plating

Beryllium Copper, Gold

Outer Conductor Material and Plating

Passivated Stainless Steel

Body Material and Plating

Passivated Stainless Steel

Dielectric Type

PTFE

RoHS Compliant

Yes

PE6206

PE6206 REV 1.1

Click the following link (or enter part number in “SEARCH” on website) to obtain additional part information including price,

inventory and certifications: Medium Power 25 Watts RF Load Up To 18 GHz With N Female Input Round Body Black

Anodized Aluminum Heatsink

PE6206

Medium Power 25 Watts RF Load Up To 18 GHz With N Female

Input Round Body Black Anodized Aluminum Heatsink
