TECHNICAL DATA SHEET

Pasternack’s RF Circulators and Isolators are available in high and low power versions with SMA or N-type connectors. These

Circulators and isolators have a minimum isolation of 18 dB and power ratings from 10 to 1,000 Watts. The frequency range

coverage is between 380 MHz and 2.2 GHz covering LTE, AWS, PCS and WiMax frequency bands. VSWR is <1.3:1 and the

insertion loss maximum is 0.35 dB

• Designs available from 380 MHz to 2.2 GHz covering Tetra, LTE, AWS, PCS, ISM and WiMax Bands

•

Isolators provide added protection to amplifiers and transmitters connected to high mismatch circuits

• Circulators are perfect for duplexer applications requiring at least 18 dB of isolation between transmit and receive

ports

• Circulators, in combination with a higher wattage termination, are usable for higher power isolator protection

Configuration

Connector 1

N Female

Connector 2

N Female

Frequency Range

1.7 GHz to 2.2 GHz

Design

Isolator

Description

Minimum

Typical

Maximum

Units

Frequency Range

1.7

2.2

GHz

Impedance

50

Ohms

Forward Power

10

Watts

Reverse Power

10

Watts

Input VSWR

1.25:1

Isolation

18

dB

.

Mechanical Specifications

Temperature

Operating Range

-20 to 65 deg C

Size

Length

2.5 in [63.5 mm]

Width

2.5 in [63.5 mm]

Height

1.02 in [25.91 mm]

.

RoHS Compliant

Yes

Click the following link (or enter part number in “SEARCH” on website) to obtain additional part information including price,

inventory and certifications: 50 Ohm N Isolator Operating From 1.7 GHz to 2.2 GHz And 10 Watts With 18 dB Isolation

PE8417

PE8417

PE8417 REV 1.0

50 Ohm N Isolator Operating From 1.7 GHz to

2.2 GHz And 10 Watts With 18 dB Isolation
