DTA143X

PNP SILICON TRANSISTOR

UNISONICTECHNOLOGIESCO.,LTD

2 of 3

www.unisonic.com.tw

QW-R206-078.F



ABSOLUTE MAXIMUM RATINGS ( TA=25°C, unless otherwise specified )

PARAMETER

SYMBOL

RATINGS

UNIT

Supply Voltage

VCC

-50

Input Voltage

-20 ~ +7

Output Current

-100

IC(MAX.)

-100

Power Dissipation

SOT-23/SOT-323/SOT-523

300

TO-92

625

TO-92SP

550

Junction Temperature

150

°C

Storage Temperature

TSTG

-55 ~ +150

°C

Note: Absolute maximum ratings are those values beyond which the device could be permanently damaged.

Absolute maximum ratings are stress ratings only and functional device operation is not implied.



ELECTRICAL CHARACTERISTICS ( TA=25°C, unless otherwise specified )

PARAMETER

SYMBOL

TEST CONDITIONS

MIN TYP MAX UNIT

Input Voltage

VI(OFF)

VCC=−5V, IO=−100μA

-0.3

VI(ON)

VO=−0.3V, IO=−20mA

-2.5

Output Voltage

VO(ON)

IO/II=−10mA/−0.5mA

-0.1

-0.3

Input Current

VI=−5V

-1.8

Output Current

IO(OFF)

VCC=−50V, VI=0V

-0.5

μA

DC Current Gain

hFE

VO=−5V, IO=−10mA

Input Resistance

3.29

4.7

6.11

KΩ

Resistance Ratio

R2/R1

1.7

2.1

2.6

Transition Frequency

VCE=−10V, IE=5mA, f=100MHz (Note)

250

MHz

Note: Transition frequency of the device
