2 / 3 page

UD9J

Preliminary

DUAL TRANSISTOR

UNISONICTECHNOLOGIESCO.,LTD

2 of 3

www.unisonic.com.tw

QW-R221-034.b



ABSOLUTE MAXIMUM RATINGS (TA=25°С, unless otherwise specified)

RATINGS

PARAMETER

SYMBOL

TR1

TR2

UNIT

Supply Voltage

VCC

-50

Input Voltage

VIN

-6 ~ +40

-40 ~ +6

IOUT

-70

Output Current

IC(MAX)

100

-100

Total Power Dissipation (Note 2)

150

Junction Temperature

+150

°C

Storage Temperature

TSTG

-55 ~ +150

°C

Notes: 1. Absolute maximum ratings are those values beyond which the device could be permanently damaged.

Absolute maximum ratings are stress ratings only and functional device operation is not implied.

2. 120mW per element must not be exceeded.



ELECTRICAL CHARACTERISTICS (TA=25°С, unless otherwise specified)

TR1

PARAMETER

SYMBOL

TEST CONDITIONS

MIN TYP MAX UNIT

VI(OFF)

VCC=5V, IOUT=100μA

0.3

Input Voltage

VI(ON)

VOUT=0.3V, IOUT=1mA

1.4

Output Voltage

VO(ON)

IOUT=5mA, IIN=0.25mA

0.1

0.3

Input Current

IIN

VIN=5V

0.88

Output Current

IO(OFF)

VCC=50V, VIN=0V

0.5

µA

DC Current Gain

hFE

VOUT=5V, IOUT=5mA

Input Resistance

KΩ

Resistance Ratio

3.7

4.7

5.7

Transition Frequency

VCE=10V, IE=-5mA, f=100MHz (Note)

250

MHz

TR2

PARAMETER

SYMBOL

TEST CONDITIONS

MIN TYP MAX UNIT

VI(OFF)

VCC=-5V, IOUT=100μA

-0.3

Input Voltage

VI(ON)

VOUT=-0.3V, IOUT=-1mA

-1.4

Output Voltage

VO(ON)

IOUT=-5mA, IIN=-0.25mA

-0.1

-0.3

Input Current

IIN

VIN=-5V

-0.88 mA

Output Current

IO(OFF)

VCC=-50V, VIN=0V

-0.5

µA

DC Current Gain

hFE

VOUT=-5V, IOUT=-5mA

Input Resistance

KΩ

Resistance Ratio

3.7

4.7

5.7

Transition Frequency

VCE=-10V, IE=5mA, f=100MHz (Note)

250

MHz
