TECHNICAL DATA SHEET

FAKRA Jack Right Angle Connector Crimp/Solder Attachment For PE-C100, RG174, RG316, Curry Color

Configuration

Connector

FAKRA Jack

Connector Interface Type

PE-C100,RG174,RG316

Cable Attachment Method (Shield/Contact)

Crimp/Solder

Body Style

Right Angle

Electrical Specifications

Impedance, Ohms

50

Mechanical Specifications

Size

Length, in [mm]

0.878 [22.3]

Width/Dia., in [mm]

0.37 [9.40]

.

Weight, lbs [g]

0.008 [3.63]

Color

Curry

Connector

Type

FAKRA Jack

Contact Material and Plating

Phosphor Bronze, Gold

Outer Conductor Material and Plating

Brass, Nickel

Body Material and Plating

Plastic

Dielectric Type

Teflon/Delrin

RoHS Compliant

Yes

Plotted and Other Data

Notes:

Values at 25 °C, sea level

FAKRA Jack Right Angle Connector Crimp/Solder Attachment For PE-C100, RG174, RG316, Curry Color from Pasternack

Enterprises has same day shipment for domestic and International orders. Our RF, microwave and fiber optic products maintain

a 99% availability and are part of the broadest selection in the industry.

Click the following link (or enter part number in “SEARCH” on website) to obtain additional part information including price,

inventory and certifications: FAKRA Jack Right Angle Connector Crimp/Solder Attachment For PE-C100, RG174, RG316,

Curry Color PE44648K

URL: http://www.pasternack.com/fakra-jack-standard-pe-c100-rg174-rg316-connector-pe44648k-p.aspx

PE44648K

PE44648K REV 01

FAKRA Jack Right Angle Connector Crimp/Solder

Attachment For PE-C100, RG174, RG316, Curry Color
