5 / 6 page

ST-4EF

Rear adjustment

ST-4EH

Side adjustment

ST-4ED

Rear adjustment

※Note the terminal position.

＜ Semi-standard products ＞

2.3

1.2

2.35

2 – 0.8

2.8

Resistance code &

Production date code

t = 0.15

0.6 W

× 2.3 L × 0.5 D

Lead-free Identification mark

2.3

3 – 0.6

2.54

2.50.5

Resistance code &

Production date code

t = 0.15

0.6 W

× 2.3 L × 0.5 D

Lead-free Identification mark

ST-42E

B CROSS SLOT DIMENSION

0.6 W

× 2.3 L × 0.5 D

Cross slot screwdriver 0 bit : 0.8 D

4.5

2.35

2 – 0.8

1.2

6.1

0.8

Resistance code &

Production date code

t = 0.15

0.6 W

× 2.3 L × 0.5 D

Lead-free Identification mark

CW rotation

ST-4

SURFACE MOUNT TRIMMERS

■ OUTLINE DIMENSIONS

Unless otherwise specified, tolerance :

± 0.3 (Unit: mm)
