Configuration

• N Male Connector

• MIL-STD-348A

• 50 Ohms

• Straight Body Geometry

• PE-B400, PE-B405, PE-C400, LMR-400, .400 inch

Interface Type

• Crimp/Solder Attachment

Features

• Max. Operating Frequency 6 GHz

• Good VSWR of 1.3:1

• Silver Plated Brass Contact

• 70 µin minimum contact plating

Applications

• General Purpose Test

• Custom Cable Assemblies

.

Description

Pasternack’s PE4550 type N male connector with crimp/solder attachment for PE-B400, PE-B405, PE-C400, LMR-400 and

.400 inch is part of our full line of RF components available for same-day shipping. Our type N male connector operates up to

a maximum frequency of 6 GHz and offers good VSWR of 1.3:1.

Our type N male connector PE4550 datasheet specifications and drawing with dimensions are shown below in this PDF.

Pasternack’s broad catalog of RF, microwave and millimeter wave connectors allows designers to configure and customize

their signal connections however they like. Whether the need is to provide an I/O for a board design, or simply create a custom

cable assembly configuration, Pasternack has the right connector for the job. Pasternack can also expertly build your custom

cable assemblies for you and ship same-day.

Electrical Specifications

Description

Minimum

Typical

Maximum

Units

Frequency Range

DC

6

GHz

VSWR

1.3:1

Operating Voltage (AC)

600

Vrms

.

Mechanical Specifications

Size

Length

1.505 in [38.23 mm]

Width/Dia.

0.827 in [21.01 mm]

.

Weight

0.072 lbs [32.66 g]

.

Click the following link (or enter part number in “SEARCH” on website) to obtain additional part information including price,

inventory and certifications: N Male Connector Crimp/Solder Attachment for PE-B400, PE-B405, PE-C400, LMR-400,

0.400 inch PE4550

PE4550 REV 1.5

N Male Connector Crimp/Solder Attachment for PE-

B400, PE-B405, PE-C400, LMR-400, 0.400 inch

RF Connectors Technical Data Sheet

PE4550
