VERTICAL CHIP TYPE ALUMINUM ELECTROLYTIC CAPACITORS FOR AUDIO[RVM]

RVM-6V331MGA5PU-R2

Features

Item Summary

330uF±20%, 6.3V, φ8x10.5mm, SMD

Lifecycle Stage

Mass Production

Standard packaging quantity (minimum)

500

Products characteristics table

Capacitance

330 uF ± 20 %

Rated Voltage

6.3 V

tanδ (max)

0.28

Operating Temp. Range

-55 to +105 ℃

Leakage current (min)

20 uA at 2 min

Rated Ripple (max)

156 mArms at 120 Hz / 105 ℃

Impedance ratio

2

___[-25℃/+20℃]

Impedance ratio

8

___[-55℃/+20℃]

Endurance

2000 hr at 105 ℃

___[Test time]

Endurance

Within ±30% of initial value

___[Capacitance change]

Endurance

300% or less of initial specified value

___[tanδchange]

Shape

Vertical Chip

(SMD)

Type

Audio

RoHS2 Compliance

Yes

REACH Compliance

Yes

Soldering

Reflow

LeadForming/Taping

Taping Embossed

External Dimensions

Dimension φD

φ8 ±0.5 mm

Dimension L

10.5 ±0.5 mm

Dimension P (F)

Typ 3.1 mm

Dimension C (d)

Typ 3 mm
