DMC3025LSDQ
Document number: DS40186 Rev. 1 - 2
9 of 11
www.diodes.com
October 2017
© Diodes Incorporated
DMC3025LSDQ
0.001
0.01
0.1
1
0.00001
0.0001
0.001
0.01
0.1
1
10
100
1000
t1, PULSE DURATION TIMES (sec)
Figure 25 Transient Thermal Resistance
D = Single Pulse
D = 0.005
D = 0.01
D = 0.02
D = 0.05
D = 0.1
D = 0.3
D = 0.5
D = 0.7
D = 0.9
R
(t) = r(t) * R
thja
thja
R
= 83C/W
thja
Duty Cycle, D = t1/ t2
