Material Specifications

Description

Material

Plating

Contact

Beryllium Copper

Gold

30 µin minimum

Insulation

PTFE

Body

Brass

Nickel

100 µin minimum

.

Environmental Specifications

Temperature

Operating Range

-65 to +165 deg C

Plotted and Other Data

Notes:

SMB Plug Right Angle Connector Crimp/Solder Attachment for RG58, RG303, RG141, PE-C195, PE-P195, LMR-195, 0.195

inch from Pasternack Enterprises has same day shipment for domestic and International orders. Our RF, microwave and

millimeter wave products maintain a 99% availability and are part of the broadest selection in the industry.

Click the following link (or enter part number in “SEARCH” on website) to obtain additional part information including price,

inventory and certifications: SMB Plug Right Angle Connector Crimp/Solder Attachment for RG58, RG303, RG141, PE-C195,

PE-P195, LMR-195, 0.195 inch PE4522

URL: https://www.pasternack.com/smb-plug-standard-rg58-connector-pe4522-p.aspx

PE4522 REV 1.1

RF Connectors Technical Data Sheet

PE4522

SMB Plug Right Angle Connector Crimp/Solder Attachment for

RG58, RG303, RG141, PE-C195, PE-P195, LMR-195, 0.195 inch
