ACT4072
TYPICAL PERFORMANCE CHARACTERISTICS
(Circuit of Figure 3, unless otherwise specified.)
VOUT
200mV/div
2A
IOUT
1A
Load Transient Response
1A
IOUT
0A
100µs/div
Load Transient Response
100µs/div
VOUT
200mV/div
VIN = 12V
VIN = 12V
