Absolute Maximum Ratings at TA = 25°C

Parameter

HLMP-R100

HLMP-0301

HLMP-0401

HLMP-0504

Units

Peak Forward Current

300

Average Forward Current[1]

DC Current[2]

Power Dissipation

135

Reverse Voltage (IR = 100 µA)

Transient Forward Current[3] (10

µs Pulse)

500

Operating Temperature Range

-20 to +100

-55 to +100

-20 to +100

°C

Storage Temperature Range

-55 to +100

Notes:

1. See Figure 5 to establish pulsed operating conditions.

2. For AlGaAs Red, Red, and Green Series derate linearly from 50

°C at 0.5 mA/°C. For Yellow Series derate linearly from 50°C at 0.2 mA/°C.

3. The transient peak current is the maximum non-recurring peak current that can be applied to the device without damaging the LED die and

wirebond. It is not recommended that the device be operated at peak current beyond the peak forward current listed in the Absolute Maximum

Ratings.
