1N65A

Power MOSFET

UNISONICTECHNOLOGIESCO.,LTD

2 of 8

www.unisonic.com.tw

QW-R502-584.B

ABSOLUTE MAXIMUM RATINGS (TC = 25°C, unless otherwise specified.)

PARAMETER

SYMBOL

RATINGS

UNIT

Drain-Source Voltage

VDSS

650

Gate-Source Voltage

VGSS

±30

Continuous Drain Current

0.5

Pulsed Drain Current (Note 2)

IDM

Avalanche Energy

Single Pulse(Note 3)

EAS

Repetitive(Note 2)

EAR

3.6

4.0

Peak Diode Recovery dv/dt (Note 4)

dv/dt

4.5

V/ns

Power Dissipation (TC=25°C)

Derate above 25°C

mW/°C

Junction Temperature

+150

°C

Operating Temperature

TOPR

-55 ~ +150

°C

Storage Temperature

TSTG

-55 ~ +150

°C

Note: 1. Absolute maximum ratings are those values beyond which the device could be permanently damaged.

Absolute maximum ratings are stress ratings only and functional device operation is not implied.

2. Repetitive Rating: Pulse width limited by maximum junction temperature

3. L=92mH, IAS=0.8A, VDD=50V, RG=0Ω, Starting TJ=25°C

4. ISD≤1.0A, di/dt≤100A/μs, VDD≤BVDSS, Starting TJ=25°C

THERMAL DATA

PARAMETER

SYMBOL

RATINGS

UNIT

Junction to Ambient

θJA

120

°C/W
