TECHNICAL DATA SHEET

75 Ohm SMC Plug Connector Solder Attachment Thru Hole PCB, .200 inch x .067 inch Hole Spacing

Configuration

Connector

SMC Plug

Connector Interface Type

Thru Hole

Cable Attachment Method (Shield/Contact)

Solder

Body Style

Straight

Electrical Specifications

Impedance, Ohms

75

Mechanical Specifications

Size

Length, in [mm]

0.5 [12.7]

Width/Dia., in [mm]

0.375 [9.53]

.

Weight, lbs [g]

0.006 [2.72]

Connector

Type

SMC Plug

Contact Material and Plating

Gold

Body Material and Plating

Brass, Nickel

RoHS Compliant

Yes

Plotted and Other Data

Notes:

Values at 25 °C, sea level

75 Ohm SMC Plug Connector Solder Attachment Thru Hole PCB, .200 inch x .067 inch Hole Spacing from Pasternack

Enterprises has same day shipment for domestic and International orders. Our RF, microwave and fiber optic products

maintain a 99% availability and are part of the broadest selection in the industry.

Click the following link (or enter part number in “SEARCH” on website) to obtain additional part information including price,

inventory and certifications: 75 Ohm SMC Plug Connector Solder Attachment Thru Hole PCB, .200 inch x .067 inch Hole

Spacing PE4369

URL: http://www.pasternack.com/smc-plug-standard-thru-hole-pcb-connector-pe4369-p.aspx

PE4369

PE4369 REV

75 Ohm SMC Plug Connector Solder Attachment Thru

Hole PCB, .200 inch x .067 inch Hole Spacing
