1

TECHNICAL DATA SHEET

2.4mm Female Connector Solder Attachment 4 Hole Flange Pin Terminal, .340 inch Hole Spacing

Configuration

Connector

2.4mm Female

Connector Interface Type

Cable Attachment Method (Shield/Contact)

Solder

Body Style

Straight

Mount Method

4 Hole Flange

Electrical Specifications

Frequency Range, GHz

DC to 50

Impedance, Ohms

50

Maximum VSWR

1.3:1

Maximum Insertion Loss, dB

0.35

Mechanical Specifications

Size

Length, in [mm]

0.825 [20.96]

Width/Dia., in [mm]

0.5 [12.70]

Height, in [mm]

0.5 [12.7]

.

Weight, lbs [g]

0.011 [4.99]

Connector

Type

2.4mm Female

Contact Material and Plating

Beryllium Copper, Gold

Contact Plating Specification

MIL-G-45204, Type II, Class 1

Body Material and Plating

Passivated Stainless Steel

Body Plating Specification

ASTM A380

Dielectric Type

PPO

Compliance Certifications (visit www.Pasternack.com for current document)

RoHS Compliant

Yes

Click the following link (or enter part number in “SEARCH” on website) to obtain additional part information including price,

inventory and certifications: 2.4mm Female Connector Solder Attachment 4 Hole Flange Pin Terminal, .340 inch Hole

Spacing PE44218

PE44218

PE44218 REV 01

2.4mm Female Connector Solder Attachment 4 Hole

Flange Pin Terminal, .340 inch Hole Spacing
