background image
USMS05
Preliminary
TVS
UNISONICTECHNOLOGIESCO.,LTD
3 of 4
www.unisonic.com.tw
QW-R215-008.a
ABSOLUTE MAXIMUM RATINGS
PARAMETER
SYMBOL
RATINGS
UNIT
ESD Voltage (HBM Contact) (Note 2)
Air
VESD
25
kV
Contact
20
kV
Peak Pulse Power (tP=8/20μs)
PPK
350
W
Operating Temperature
TJ
-55~+125
°C
Storage Temperature
TSTG
-55~+150
°C
Note: 1. Absolute maximum ratings are those values beyond which the device could be permanently damaged.
Absolute maximum ratings are stress ratings only and functional device operation is not implied.
2. IEC 61000-4-2.
ELECTRICAL CHARACTERISTICS
PARAMETER
SYMBOL
TEST CONDITIONS
MIN
TYP MAX UNIT
Reverse Stand-Off Voltage
VRWM
5
V
Reverse Breakdown Voltage
VBR
IT=1mA
6
V
Reverse Leakage Current
IR
VRWM=5V, T=25°C
20
μA
Clamping Voltage
VC
IPP=5A, tp=8/20μs
9.8
V
IPP=24A, tp=8/20μs
14.5
V
Peak Pulse Current
IPP
tp=8/20μs
24
A
Junction Capacitance
Cj
Between I/O Pins and Ground
VR=0V, f=1MHZ
325
400
pF
