21.11.2011

LED375-series

2 of 8

Type

Viewing

Half Angle

Outer

Dimension

Dimension

Figure

[Unit: mW/sr]

Min.

Typ.

Max.

LED375-01

±8°

7.0

Ø 5

1

LED375-02

±5°

11.0

Ø 5

2

LED375-03

±10°

7.0

Ø 5

3

LED375-04

±20°

2.5

Ø 5

4

LED375-05

±50°

0.5

Ø 5

5

LED375-06

±4°

13.0

Ø 5

6

LED375-09

±25° (long)

Ø 5

7

±10° (short)

Oval

LED375-46

Ø 5

8

LED375-41

±14°

Ø 4

9

LED375-42

±20°

Ø 4

10

LED375-31

Ø 3

11

LED375-33

±13°

4.0

Ø 3

12

LED375-34

Ø 3

13

LED375-36

±25°

2.0

Ø 3

14

* Radiant Power is measured by S3584-08

* Radiant Intensity is measured by Ando Optical Multi Meter AQ2140 & AQ2741

The above specifications are for reference purpose only and subjected to change without prior notice.

Outer Dimensions

Figure-1 Ø 5Mold (Type 01)

Figure-2 Ø 5Mold (Type 02)

Figure-3 Ø 5Mold (Type 03)

Figure-4 Ø 5Mold (Type 04)
