EL9100 Series

www.EtherWAN.com

2

rev. A1.1

DIPSwitch

•No.1: LFPT on/off

•No.2: Alarm for copper port on/off

•No.3: Alarm for fiber port on/off

•No.4: Auto-negotiation for fiber port on/off

AlarmContact

•Relay contact rating with current

1A @ 30VDC, 0.5A @ 120VAC

Environment

OperatingTemperature

•-40°C to 75°C (-40°F to 167°F)

Tested @ -40°C to 85°C (-40°F to 185°F)

StorageTemperature

•-40°C to 85°C (-40°F to 185°F)

AmbientRelativeHumidity

•5% to 95% (non-condensing)

RegulatoryApprovals

ISO

•Manufactured in an ISO9001 facility

EMI

FCCPart15B,ClassA

EN61000-6-4

EN55022

EN61000-3-2

EN61000-3-3

Safety

UL508

EMS

EN61000-6-2

•EN61000-4-2 (ESD Standards)

•EN61000-4-3 (Radiated RFI Standards)

•EN61000-4-4 (Burst Standards)

•EN61000-4-5 (Surge Standards)

•EN61000-4-6 (Induced RFI Standards)

•EN61000-4-8 (Magnetic Field Standards)

EnvironmentalTestCompliance

IEC60068-2-6Fc(VibrationResistance)

IEC60068-2-27Ea(Shock)

FEDSTD101CMethod5007.1(Freefallw/package)

IndustrialCompliance

NEMATS1&TS2

Hardware Specifications

Technology

Standards

•IEEE802.3 10BASE-T

•IEEE802.3u 100BASE-TX

•IEEE802.3ab 1000BASE-T

•IEEE802.3z 1000BASE-SX/1000BASE-LX

•IEEE802.3x full duplex and flow control

ForwardandFilteringRate

•1,488,100pps for 1000Mbps

ProcessingType

•Auto Negotiation

•Half duplex back-pressure and IEEE802.3x full-duplex flow

control

•Auto-MDI/MDIX

Power

InputVoltage

•12 to 48VDC (Terminal Block)

•12VDC (DC Jack)

PowerConsumption

•7.68W Max, 0.16A @ 48VDC

Protection

•Overload current protection

•Reverse polarity protection

Mechanical

Casing

•Aluminum Case

•IP30

Dimensions

•50mm (W) x 110mm (D) x 135mm (H)

(1.97" (W) x 4.33" (D) x 5.31" (H))

Weight

•0.8Kg (1.76lbs.)

Installation

•DIN-Rail (Top hat type 35mm), Panel, or Rack mounting

Interface

EthernetPort

•10/100/1000BASE-TX: 1 port

•1000BASE-SX/LX/BX: 1 port

LEDIndicators

•Per Unit: Power1

Power2

Power3

Fault

LFPT

•Per 10/100/1000BASE-TX Port: Link/ACT

100M

1000M

Full-duplex/Collision

•Per 1000SX/LX/BX Port: Link/Act
