Heat Sink SPL-Coax

• Heat Sink for SPL type coaxial laser diodes

• Aluminium

• 16 x 16 x 8 mm

• Aperture diameter 6.2 mm

Outline

All dimensions in mm

© All Rights Reserved

The above specifications are for reference purpose only and subjected to change without prior notice

Description

Heat Sink SPL-Coax has been specifically designed for the SPL type fiber pigtailed laser diodes. It greatly increases the heat

dissipation capabilities of the diode and helps to increase performance and life time. It is made from CNC cut Aluminium with an

aperture diameter of 6.2 mm and comes with a grub screw to easily fixate the laser diode. For best performance it is advised to

add thermal conductive paste between diode and heat sink, and to mount the heat sink on a metal foundation plate.
