Table 3: Absolute Maximum Ratings

Absolute Maximum Ratings are those values beyond which damage to the device may occur. Functional operation under these conditions is

not implied.

Note 1: All card contacts are protected against any short with any other card contact.

Note 2: Method 3015 (HBM, 1500

Ω, 100 pF) 3 positive pulses and 3 negative pulses on each pin referenced to ground.

Table 4: Thermal Data

RECOMMENDED OPERATING CONDITIONS

Symbol

Parameter

Min

Max

Unit

-0.3

7

V

Voltage on pins XTAL1, XTAL2, 5V/3V, RSTIN, AUX2UC,

AUX1UC, I/OUC, CLKDIV1, CLKDIV2, PORADJ, CMDVCC,

PRES, PRES and OFF

-0.3

V

Voltage on card contact pins I/O, RST, AUX1, AUX2 and CLK

-0.3

V

9V

ESD1

MIL-STD-883 class 3 on card contact pins, PRES and PRES

(Note 1, 2)

-6

6

kV

ESD2

MIL-STD-883 class 2 on µC contact pins and RSTIN (Note 1, 2)

-2

2

kV

Symbol

Parameter

Condition

Value

Unit

Thermal Resistance Junction-ambient Temperature

In free air

70

K/W

Symbol

Parameter

Min.

Typ.

Max.

Unit

Temperature Range

-25

85

°C
