background image
DTC143E
NPN EPITAXIAL SILICON TRANSISTOR
ABSOLUATE MAXIUM RATINGS (Ta = 25℃)
PARAMETER
SYMBOL
RATINGS
UNIT
Supply Voltage
VCC
50
V
Input Voltage
VIN
-10 ~ +30
V
Output Current
IC
100
mA
Power Dissipation
PD
200
mW
Junction Temperature
TJ
150
℃
Storage Temperature
TSTG
-40 ~ +150
℃
ELECTRICAL CHARACTERISTICS (Ta= 25℃, unless otherwise specified.)
PARAMETER
SYMBOL
TEST CONDITIONS
MIN
TYP
MAX
UNIT
VI(off)
VCC= 5V, IO=100μA
0.5
Input Voltage
VI(ON)
VO= 0.3V, IO= 20mA
3
V
Output Voltage
VO(ON)
IO/II= 10mA / 0.5 mA
0.1
0.3
V
Input Current
II
VI= 5V
1.8
mA
Output Current
IO(off)
VCC= 50V , VI=0V
0.5
μA
DC Current Gain
GI
VO= 5V, IO= 10mA
20
Input Resistance
R1
3.29
4.7
6.11
kΩ
Resistance Ratio
R2/R1
0.8
1
1.2
Transition Frequency
fT
VCE= 10 V, IE= -5mA, f=100MHz *
250
MHz
*Transition frequency of the device
UNISONIC TECHNOLOGIES CO., LTD
2
www.unisonic.com.tw
QW-R220-015.A
