LCD Switches

Programmable OLED Video Switch and Display

IS Series

sales@greatecs.com

www.greatecs.com

SMARTSWITCH PART NUMBER & DESCRIPTION

SMARTSWITCH LCD SPECFICATIONS

Characteristics of Display

Display Device

Color OLED display module

Display Mode

Passive matrix

Viewing Area

12.9mm x 9.9mm (horizontal x vertical)

Pixel Format

52RGB x 36 pixels (horizontal x vertical)

Pixel Size

0.21mm x 0.22mm (horizontal x vertical)

Interface

Serial (SPI) interface

Number of Colors

65,536 Colors (16bit: B 5bit/G 6bit/R 5bit)

or 256 Colors (8bit: B 3bit/G 3bit/R 2bit)

Operating Temperature Range

–20°C ~ +70°C (–4°F ~ +158°F)

Storage Temperature Range

–30°C ~ +80°C (–22°F ~ +176°F)

Operating Life Time (Display)

15,000 hours (40% pixels ON)

Absolute Maximum Ratings

Items

Symbols

Ratings

Supply Voltage for

Logic/Interface

VDD

–0.3V to +4.0V

Supply Voltage for Drive

VCC

0.3V to +19.0V

Input Voltage

–0.3V to V DD +0.3V

Current Consumption

(Temperature at 25°C, V DD = 2.8V, V CC = 16.0V)

Items

Symbols Min Typical

Max

All-Pixels-On Mode

*Drive System Power Current

ICC1

––

3.5mA

4.5mA

All-Pixels-On Mode

*Logic/IF System Power Current

IDD1

–– 0.16mA 0.2mA

Sleep Mode

**Drive System Power Current

ICC2

––

10A

Sleep Mode

**Logic/IF System Power Current

IDD2

––

10A

*All pixels shall be turned on with the maximum level gray scale

**All pixels shall be turned o (while chip is operating)

Optical Characteristics (Temperature at 25°C, Initial Value: 87 x 0F)

Items

Min

Typical

Max

Unit

Remarks

Luminosity

100

125

cd/m 2

White

(All pixels on)

White Color

Coordinate

(x)

0.29

0.31

0.35

––

(y)

0.30

0.35

0.40

––

Red Color

Coordinate

(x)

0.60

0.64

0.68

––

(y)

0.31

0.35

0.39

––

Green Color

Coordinate

(x)

0.26

0.30

0.34

––

(y)

0.59

0.63

0.67

––

Blue Color

Coordinate

(x)

0.10

0.14

0.18

––

(y)

0.12

0.18

0.24

––

Contrast Ratio

100

––

Part Number

Display Description

OLED

Pixel Format

ISC01P

Straight PC Terminals

Color OLED

Display Module

65,536 Colors

52RGB x 36 Pixels

Horizontal x Vertical

Absolute Maximum Ratings

Items

Symbols Minimum

Typical

Maximum

Supply Voltage for

Logic/Interface

VDD

2.4V

2.8V

3.5V

Supply Voltage for Drive

VCC

15.0V

16.0V

17.0V

Input High Level Voltage

VIH

0.8 x V DD

––

Input Low Level Voltage

VIL

––

0.2V x V DD
