AD8657

Rev. A | Page 14 of 24

TIME (40µs/DIV)

–0.4

–0.2

VSY = ±1.35

AV = –10

RL = 1MΩ

INPUT

OUTPUT

Figure 45. Positive Overload Recovery

TIME (40µs/DIV)

0.2

0.4

–1

–2

VSY = ±1.35V

AV = –10

RL = 1MΩ

INPUT

OUTPUT

Figure 46. Negative Overload Recovery

TIME (10µs/DIV)

+5mV

–5mV

VSY = 2.7V

RL = 100kΩ

CL = 10pF

INPUT

OUTPUT

ERROR BAND

Figure 47. Positive Settling Time to 0.1%

TIME (40µs/DIV)

–1

–2

VSY = ±9V

AV = –10

RL = 1MΩ

INPUT

OUTPUT

Figure 48. Positive Overload Recovery

TIME (40µs/DIV)

–5

–10

VSY = ±9V

AV = –10

RL = 1MΩ

INPUT

OUTPUT

Figure 49. Negative Overload Recovery

TIME (10µs/DIV)

+5mV

–5mV

VSY = 18V

RL = 100kΩ

CL = 10pF

INPUT

OUTPUT

ERROR BAND

Figure 50. Positive Settling Time to 0.1%
