AD8033/AD8034
Rev. D | Page 15 of 24
+VS
49.9Ω
1µF
+
10nF
AD8033/AD8034
VOUT
+
–
–VS
–VS AC
1V p-p
Figure 49. Negative PSRR
49.9
Ω
+VS
VIN
–VS
1µF
1µF
+
10nF
AD8033/AD8034
10nF
+
976Ω
VOUT
1kΩ
1kΩ
49.9Ω
1kΩ
1kΩ
Figure 50. CMRR
+VS
+
–
+VS AC
1V p-p
49.9Ω
VOUT
–VS
AD8033/AD8034
10nF
1µF
+
Figure 51. Positive PSRR
–VS
+VS
–VS
+VS
A
+
–
499Ω
1kΩ
1kΩ
1kΩ
TO PORT 2
B
+
–
1kΩ
1kΩ
1kΩ
499Ω
TO PORT 1
50Ω
+
–
VIN
Figure 52. Crosstalk
