1 / 4 page  SMD Unshielded Power Inductors – SSL-HC Series SSL-HC Series This series is specially designed for high current, low voltage DC-DC converter applications. Its simple, rugged design provides current ratings normally available in larger packages. With tinned self-leaded construction, SSL-HC series can achieve very low DCR values and excellent solderability. In addition, they have very low resistance. Standard parts shown in catalogue and custom values are also available. Features Applications RoHS compliant For high current, low voltage DC-DC converter applications Notebook computers step-up and step-down converters memory programmers, etc Product Identification Packaging: T：Tape and Reel , B：Bulk Shape and Dimension Recommended Pattern SSL0503HC Dimension in mm A B C D 8.89 +0 6.10 +0 5.00 +0 5.84 Dimension in mm A B C D 1.91 4.06 8.89 5.08 SSL0804HC Dimension in mm A B C 13.21 +0 9.91 +0 6.35 +0 Dimension in mm A B C D 1.52 4.06 11.68 8.64 |
