NC6MP-B

NC3FP-1

NC3MP

NC3FP-1

NC3MPR-HD

NC5MPR-HD

NC3MPR-HD

NC5MPR-HD

NC5FX-HD

innovative

solutions

I superior quality

• Male and female available in 3-6 pin configurations;

7 pin versions available in female only

• Smallest available hard wiring receptacles with large solder cups

• Male and female use different mounting hole dimensions

and do not fit in same mounting hole

• Front mountable only

• One piece version – insert is NOT removable from shell

• Short female receptacle

• Compatible with Switchcraft® DxM, DxF; Cannon XLRx31, XLRx32

• 6 pole female version available with Switchcraft contact

arrangement

XLR

Chassis

Connectors

XLR

Chassis

Connectors

P Series

Through hole fastening

• IP 65 - in combination with NC*FX-HD cable connectors

• Perfect for outdoor applications

• Sealing gasket for water tight panel mount

• Gold plated contacts

MPR-HD Series

Sealing Gasket

*: 3 - 5 contacts
